EZ Solar Junction Box – Asphalt Shingle
$99.40
Stock: Available
Easy-install junction box for secure solar connections on shingle roofs.
Canada Wide Shipping
Orders ship in 1-2 days
Pickup from nearest warehouse
24/7 Customer support
Secure transaction
- Description
- Additional information
- Reviews (3)
- Features
- Technical Specs
- Documents
Description
Description
The EZ Solar Junction Box – Asphalt Shingle, specifically the JB-1.XL model designed for larger systems, provides a convenient solution for solar installations. It offers a spacious interior while retaining the features that installers appreciate in the original JB-1 model.
The larger size of the JB-1.XL box allows for more space inside, accommodating larger systems, and reducing the number of junction boxes required. This not only simplifies the installation process but also helps to lower overall costs.
Installing the EZ Solar Junction Box is quick and hassle-free. It comes with a pre-installed Din Rail, further streamlining the installation process. The box is constructed from advanced durable polycarbonate and superior components, ensuring longevity and durability in various weather conditions.
The EZ Solar Junction Box – Asphalt Shingle has a maximum voltage rating of 1,000 Volts and is available in two models: JB-1.2 with a maximum current rating of 80 Amps and JB-1.XL with a maximum current rating of 120 Amps. It supports wire sizes ranging from 14 AWG to 6 AWG.
The enclosure of the junction box is rated as Type 3R, offering protection against environmental elements. The box is suitable for roof slopes within the range of 2.5 – 12:12 and accommodates fittings with a maximum size of 1″ for side walls and floor pass-through.
The EZ Solar Junction Box – Asphalt Shingle meets UL1741 and CSA C22.2 No. 290 standards, ensuring compliance with safety and performance requirements. Approved wire connectors conforming to UL1741 and CSA C22.2 No. 290 are compatible with this junction box.
Additional information
Additional information
| Weight | 2 lbs |
|---|---|
| Dimensions | 9 × 9 × 7 in |
Reviews (3)
3 reviews for EZ Solar Junction Box – Asphalt Shingle
Add a review
Features
- Minimum number of components.
- Patented design.
- Fast and easy installation.
- 100 cubic inches (Systems 7kW and smaller).
- Special Design: Made specifically for Asphalt Shingle installations, ensuring it works well with this type of roofing.
- Easy to Install: Designed for simple installation, so both professionals and DIY enthusiasts can set it up easily.
- Model JB-1.2: Known as JB-1.2, showing it’s made for Asphalt Shingle solar setups.
- Secure Connection: Ensures a safe and dependable link between solar panels, allowing smooth electrical flow in the solar energy system.
- Sturdy Build: Constructed with strong materials to withstand typical environmental conditions in Asphalt Shingle roofs, guaranteeing it lasts a long time.
- Compatibility: Specifically made to smoothly integrate with solar panel systems on Asphalt Shingle roofs, offering an effective solution for solar energy needs.
Technical Specs
Maximum Voltage: 1,000 Volts
Maximum Current: 80 Amps
Allowable Wire: 14 AWG – 6 AWG
Spacing Requirement: Maintain at least ½” spacing between uninsulated live parts and fittings for conduit, armored cable, and uninsulated live parts of opposite polarity.
Enclosure Rating: Type 3R
Roof Slope Range: 2.5 – 12:12
Max Side Wall Fitting Size: 1”
Max Floor Pass-Through Fitting Size: 1”
Ambient Operating Conditions: (-35°C) – (+75°C)
Compliance and Safety: JB-1.2 Compliance: Meets UL1741 standards
Wire Connectors: Approved connectors must conform to UL1741
Documents
Related Products
-
Combiner Boxes
Midnite Solar – 12 Breaker Combiner Box
Original price was: $606.86.$574.00Current price is: $574.00. -
Combiner Boxes
Midnite Solar – 6 Breaker Combiner Box
Original price was: $343.00.$301.00Current price is: $301.00. -
Combiner Boxes
Midnite Solar – 3 Breaker Combiner Box
Original price was: $268.80.$263.20Current price is: $263.20.
